Striker AWD 2" Lift Kit (Complete) - Sprinter AWD (2023-Present 2500 Single Rear Wheel)

The Van Compass Striker AWD lift kit creates the clearance needed to fit larger tires and push deeper into back country landscapes with confidence in the increased capability. Through hours of careful development and design, we've created a system that lifts the van with as few compromises to the original design parameters of the vehicle as possible. Using a mix of machined and welded spacers, we move the front subframe to allow for the CVs, tie rods, and control arms to all cycle in their original geometry range set by Mercedes. At the rear, a taller version of our Mini Leaf Spring pack is paired with longer sway bar links, shock relocation brackets, and bump stop spacers to ensure that nothing binds, over-extends, or can over-compression on axle articulation. With proper wheel offset and fender trimming, fitment of a 35 x 12.50 tire is possible, for a huge increase in traction and ground clearance.

INCLUDED COMPONENTS:

Front 2" strut spacers
Front 2" subframe drop spacers
Engine and transmission mount 2" lift spacers
Front differential re-clocking cams
CNC Machined 2" steering shaft extension
Low pressure power steering hose extension
Front brake line relocation brackets
6-leaf Mini Leaf Spring pack
Extended rear sway bar links
Rear lower shock relocation brackets
Rear bump stop drop brackets
Wind assist or headlight leveling sensor bracket
All necessary hardware and detailed instructions
